PE100 Polyethylene, 1 2 3 4inch HDPE Roll Pipe

PE100 Polyethylene, 1 2 3 4inch HDPE Roll Pipe

"Senpu" PE pipe features 1. Long working lifespan as min. 50 years. 2. Excellent performance on shock-resistance and low
Basic Info
Model NO. senpu pipe
Usage Water Supply Pipe
Transport Package Standard Packing
Specification PE80/PE100
Trademark Senpu
Origin China
HS Code 3917210000
Production Capacity 20000t/Year
Product Description
"Senpu" PE pipe features
1. Long working lifespan as min. 50 years.
2. Excellent performance on shock-resistance and low-temperature resistance, brittle temperature could be -70°C.
3. Good Chemistry stability, corrision resistance of all kinds of acid,alkali and salt.
4. Good toughness, warp and earthquake resistance.
5. Sanitary enough, no secondary pollution to drinking water(pipe for water supply).
6. Light weight, convenient to carry and transport.
7. Easy to construct, simple welding process,low project cost.
8. Heat or electric fusion connection, reliable property, low rate of fracture or leakage.
9. High quality raw material, PE80 or PE100.
10. Reach or above the national standard GB/T13663-2000.
Suitable for liquid tranportation which temperature not above 40°C(buried or hided).

PE pipe for water supply specification:
PE Pipe for Water Supply(PE100)
Nominal outside diameter dn(mm)Nominal wall thickness(mm)
PN0.6PN0.8PN1.0PN1.25PN1.6
SDR26SDR21SDR17SDR13.6SDR11
20----2.3
25---2.3 2.3
32--2.3 2.4 3.0
40-2.3 2.4 3.0 3.7
502.3 2.4 3.0 3.7 4.6
632.4 3.0 3.8 4.7 5.8
752.9 3.6 4.5 5.6 6.8
903.5 4.3 5.4 6.7 8.2
1104.2 5.3 6.6 8.1 10.0
1254.8 6.0 7.4 9.2 11.4
1405.4 6.7 8.3 10.3 12.7
1606.2 7.7 9.5 11.8 14.6
1806.9 8.6 10.7 13.3 16.4
2007.7 9.6 11.9 14.7 18.2
2258.6 10.8 13.4 16.6 20.5
2509.6 11.9 14.8 18.4 22.7
28010.7 13.4 16.6 20.6 25.4
31512.1 15.0 18.7 23.2 28.6
35513.6 16.9 21.1 26.1 32.2
40015.3 19.1 23.7 29.4 36.3
45017.2 21.5 26.7 33.1 40.9
50019.1 23.9 29.7 36.8 45.4
56021.4 26.7 33.2 41.2 50.8
63024.1 30.0 37.4 46.3 57.2
71027.2 33.9 42.1 52.2 63.6
80030.6 38.1 47.4 58.8 72.7
90034.4 42.9 53.3 66.2 81.8
100038.2 47.7 59.3 73.5 -
120046.2 57.1 70.6 --
